Products Description
The 2513 Uv Flatbed Printer is a digital inkjet printing device that uses ultraviolet (UV) curing technology and is designed for high-precision color printing on a variety of flat materials. Its "2513" usually refers to the size of the printing platform, which is 2.5 meters by 1.3 meters, and is suitable for printing on medium and large materials. It can be printed on a variety of materials such as glass, tiles, metal, acrylic, wood, leather, PVC, etc.
Advantages
1. Wide printing range
The device supports a maximum printing size of 2560×1360mm, which can meet the pattern output requirements of medium to large materials. It is suitable for pattern printing of various flat materials such as advertising signs, decorative panels, glass, metal, acrylic, etc., which improves the applicability and flexibility of the equipment.
2. Multi-color printing combination
The flatbed printer supports CMYK basic four-color printing, and is additionally equipped with light cyan, light magenta (LC/LM), white ink and varnish channels. This combination can achieve richer color transitions, and can print white ink on dark or transparent materials, and perform local glazing with varnish to enhance the image's expressiveness and visual texture.
3. Ink dries as soon as it is printed
The flatbed printer is equipped with LED UV lamps for curing, and has the characteristics of low energy consumption and long life. The ink is instantly cured by ultraviolet rays during the printing process, avoiding the waiting time for traditional ink to dry, improving production efficiency, and reducing problems such as image blur caused by wet ink.
4. Stable drive system structure
The Y axis of the flatbed printer is driven by a dual servo motor, equipped with a reducer and imported double Y screws to enhance the stability and accuracy of motion control. This structure can reduce mechanical errors, improve the line smoothness of the image and the consistency of repeated printing.
Specifications
|
Model |
XMS-2513-i3200U/G5/G5istandsrd model G6 Linear motor/standard model |
||||||
|
Royal mainboard |
Honson mainboard |
||||||
|
Appearance |
Black grey +medium grey |
||||||
|
Print Head |
EPSON i3200U/G5/G5i/G6(2-8) |
||||||
|
Color |
CMYK+Lc+Lm+White+Varnish |
||||||
|
Printing Speed (sqm/h) |
dpi Printhead |
GEN5 |
i3200U |
GEN5i |
Standard Model GEN6 |
Linear motor GEN6 |
|
|
720x600dpi(4PASS) |
26m²/h |
16m²/h |
4m²/h |
32m²/h |
42m²/h |
||
|
720x900dpi(6PASS) |
20m²/h |
12m²/h |
3m²/h |
24m²/h |
33m²/h |
||
|
720x1200dpi (8PASS) |
15m²/h |
10m²/h |
2m²/h |
18m²/h |
24m²/h |
||
|
Print size(mm) |
2560x1360 |
||||||
|
Print Thickness(mm) |
0.1-175(UItra-high customizable) |
||||||
|
Curing System |
LED UVLights |
||||||
|
Image Format |
TIFF/JPG/EPS/PDF/BMP |
||||||
|
Rip Software |
PHOTOPRINT/Maintop/Riin Rip-honson |
||||||
|
Negative pressure |
White and color separate negative pressure |
||||||
|
Power Supply |
AC220V 50HZ士10% |
||||||
|
Temperature |
20-32℃ |
||||||
|
Humidity |
40-75% |
||||||
|
Power |
3500/5500W |
||||||
|
Appearance Size (mm) |
Length /Width /Height:4470/2107/(1283-1383) (Trolley head adjustable height 175mm) |
||||||
|
Data Transmission |
TCP/IP network interface |
||||||
|
NetWeight(kg) |
1000/1350 |
||||||
|
Wooden box size(mm) |
4621X2260X1620 |
||||||
|
Suction system |
6 partitions,two 750W brand fans |
||||||
|
Y-axis |
Double servo motor drive,with reducer |
||||||
|
Lead screw |
Imported brand double Yscrew |
||||||
|
Automatic height measurement |
The system drives the automatic height measurement function |
||||||
